Raspberry Pi 4 Board ONLY
Raspberry Pi 4 Board ONLY
We only allow 1 Board per Customer of this Product. We will refund orders beyond the limits set. This is to allow access to be Raspberry Pi Boards to more people.
Processor: | Broadcom BCM2711, quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5 GHz |
Memory: |
1GB LPDDR4-2400 SDRAM 2GB LPDDR4-2400 SDRAM 4GB LPDDR4-2400 SDRAM 8GB LPDDR4-2400 SDRAM |
Connectivity: | 2.4 GHz and 5.0 GHz IEEE 802.11b/g/n/ac wireless LAN, Bluetooth 5.0, BLE 2 x USB 3.0 ports 2 x USB 2.0 ports |
GPIO: | Standard 40-pin GPIO header (fully backwards-compatible with previous boards) |
Video & Sound: | 2 x micro HDMI ports (up to 4Kp60 supported) 2-lane MIPI DSI display port 2-lane MIPI CSI camera port 4-pole stereo audio and composite video port |
Multimedia: | H.265 (4Kp60 decode); H.264 (1080p60 decode, 1080p30 decode); OpenGL ES, 3.0 graphics |
SD card support: | Micro SD card slot for loading operating system and data storage |
Input power: | 5V DC via USB-C connector (minimum 3A) 5V DC via GPIO header (minimum 3A) Power over Ethernet (PoE)-enabled (requires separate PoE HAT) |
Environment: | Operating temperature 0-50°C |
Compliance: | For a full list of local and regional product approvals, please visit https://www.raspberrypi.org/documentation/hardware/raspberrypi/conformity.md |
Production lifetime: | The Raspberry Pi 4 Model B will remain in production until at least January 2026 |
Raspberry Pi 4 Model B is the latest product in the popular Raspberry Pi range of computers. It offering improved and ground-breaking performance compared to the prior-generation Raspberry Pi 3 Model B+ while retaining backwards compatibility and similar power consumption. For the end user, Raspberry Pi 4 Model B provides desktop performance comparable to entry-level x86 PC systems.
This product's key features include the following:
- high-performance 64-bit quad-core processor
- dual-display support at resolutions up to 4K via a pair of micro-HDMI ports
- hardware video decode at up to 4Kp60
- up to 8GB of RAM
- dual-band 2.4/5.0 GHz wireless LAN
- Bluetooth 5.0
- Gigabit Ethernet
- USB 3.0
- PoE capability (via a separate PoE HAT add-on).
The dual-band wireless LAN and Bluetooth have modular compliance certification, allowing the board to be designed into end products with significantly reduced compliance testing, improving both cost and time to market.
